TECON-Form Film Faced Plywood
TECON-Form Film Faced Plywood is a range of durable, flat, and water-resistant shuttering panels designed for concrete formwork applications. Available in various veneer materials including poplar, hardwood, birch, and birch X-life, the plywood series offers different performance levels, reuse cycles, and surface finishes to meet diverse project and budget requirements. It is widely used in conventional formwork, H20 timber beam systems, and panel formwork applications.
Features & Benefits
TECON-Form Film Faced Plywood Features and Benefits
- Multiple Grade Options – Available in various quality grades and reuse levels, providing flexible solutions from economical to high-end project requirements.
- Smooth Concrete Finish – Produces clean, flat, and consistent concrete surfaces with reduced surface treatment requirements.
- Easy Processing on Site – Can be easily nailed, cut, drilled, and adjusted to accommodate different structural dimensions and shapes.
- Lightweight & Easy Handling – Individual panels can be manually transported and positioned by workers on site for improved handling efficiency.
- Versatile Formwork Application – Suitable for both horizontal and vertical concrete structures across different formwork systems.
TECON-Form Film Faced Plywood Application
Widely used in construction projects requiring concrete shuttering for walls, slabs, columns, beams, and other structural elements.
Technical Specifications
TECON-Form Film Faced Plywood Options
| Plywood Series | Nominated Thickness | Sizes | Approximate Uses |
| System Type | Shuttering Boards | ||
| TECON-Form Poplar | 12/15/18/21 mm | 1220×2440 mm 1250×2500 mm 915×1830 mm |
4-10 times |
| TECON-Form Hardwood | 12/15/18/21 mm | 1220×2440 mm 1250×2500 mm 915×1830 mm |
8-15 times |
| TECON-Form Birch | 12/15/18/21 mm | 1220×2440 mm 1250×2500 mm 915×1830 mm Customized* |
20-50 times |
| TECON-Form AUS | 9/17 mm | 1200×1800 mm 1200×2400 mm |
12-20 times |
| TECON-Form 3-Solid | 21/27mm | W: 500/1000/2000 mm L: 1000/2000/2500/ 3000 mm |
10-40 times |
| TECON-Form Plas-tech | 12/15/16/18/20/21/ 27/30 mm |
1220×2440mm 1220×2745mm 1220×3050mm Customized* |
25-60 times |
Formwork Accessories Products You May Also Like
All Products
Projects Show
All Projects
Your burning questions, answered
How to get a quotation?
You can send us your material list to request a quotation, or you can also simply send us the structural drawing and project information for complete formwork & scaffolding proposal via the below contacts.
Email: info@teconform.com
Phone: +86-512-65650586
Mobile: +86-13862020161.
What is the payment term?
By T/T or L/C.
What is the lead time?
For climbing formwork, self-climbing platform, plastic formwork, we have stock in our warehouse. The preparation of loading will be within 10 to 15 days.
For H20 timber beam, TECON-Form Shuttering, the lead time is from 15 to 25 days.
For other systems, the lead time is from 30 to 45 days.
For a more accurate lead time, don’t hesitate to contact us for a specific product based on your quantity.
